Handheld ultrasonic flowmeter

Handheld ultrasonic flowmeter

Applicable mediumLiquid, water, sewag

Not applicableGas

Handheld ultrasonic flow meter adpot clamp-on type sensors, which is easily mountable on existing pipes. Suited for a wide range of liquids, deionized water, cooling water, chemical solution, drinking water, sea water, oil, tap water, hot water, industrial water, corrosive liquids.
0371-26665688 13353783998
Description of product details

Features


High Accuracy measuring

Linearity: better than 0.5%, Repeatability: better than 0.2%, Accuracy: better than ±1%

Small size, Light weight

Dimensions: 200×93×33mm; Weight:390g

Non-intrusive measuring

Non-intrusive, clamp-on transducer, no pressure drop, no pipe disturbance.

Wide measuring range

Several types transducer for selection, measuring pipe size from DN15mm to DN6000mm

Large LCD display

Display instantaneous flow, accumulated flow (positive, negative and net), velocity, working status etc.

Built-in data logger

Built-in 24K data logger, store over 2000 lines measuring data


Technical parameters


Items?

Performance?and?Parameter?

Main?Unit?

Principle?

transit-time?ultrasonic?flow?meter?

Accuracy?

Accuracy?:over?1%-2%;?Repeatability:?over?0.2%?

Display?

4?line?x?16?character?LCD?with?backlight?

Dimension?

200*93*33cm:???390g?

Operation?

Support?16?key?light?touch?keyboard?and?the?Simulation?keyboard?software?

Data?interface?

Insulate?RS232?serial?interface,?upgrade?the?flew?meter?software?by?computer,?

support?the?MODBUS,?etc.?

Signal?Output?

1?way?OCT?output?

Special?Cable?

Twisted-pair?cable,?;Select?the?RS232?communication.;?

Generally,?the?standard?is?5m*2,?optional?10m*2??

Pipe?Condition?

Pipe?Material?

Steel,?Stainless?steel,?Cast?iron,?Copper,?Cement?pipe,?PVC,?Aluminum,?Glass?steel?product,?liner?is?allowed.?

Pipe?Diameter?

DN?15---6000mm?

Straight?length?pipe?

Transducer?installation?should?be?satisfied:?upstream10D,?downstream?5D,?30D?from?the?pump.

Measuring?Medium?

Type?of?Liquid?

Water?;?Ultra-pure?liquids;?Solvents?and?other?liquids??

Temperature?

Standard?Transducer:?-30--90℃;?High-temperature?transducer:?-40--160℃?

Turbidity?

under?10000ppm?and?less?bubble??

Flow?rate?

0--±10m/s?

Flow?Direction?

Measuring?two?(plus-minis)?direction?of?flow?rate??

Working?Environment?

Temperature?

Main?Unit:?-20--60℃?

Flow?transducer:?-40--160℃;???

Temperature?transducer:?according?to?the?customer’s?demands.?

Humidity?

Main?Unit:?85%?RH?

Power?Supply?

AC??110V-240V??



photobank (10).jpg

photobank (13).jpg

photobank (9).jpg
