Flange Clamping Vortex Flowmeter
Flange Clamping Vortex Flowmeter
Applicable mediumLiquid, hot oil, pur
Not applicable
Flange connection vortex flow meter feature
1. Simple structure, no moving parts wear;
2. Flange clamping connection method, easy installation.
3. High accuracy and good reliability, don’t need on-site debugging?
4.Unique design of the amplification board, gas or liquid can be used
5. Can
be long-distance transmission of flow signals, and computer networking,
centralized management; It has a variety of data transmission methods,
including 4-20ma output, frequency output, RS485 output, if you need to
pass the RS485 protocol to receive data, we can be satisfied. Of course,
we will also instruct you on how to install .
Technical parameters
Measuring diameter |
DN15~DN300 |
Relative humidity |
5℃~90℃ |
Atmospheric pressure |
86~106kPa |
Medium temperature |
-40℃~+200℃;-40℃~+280℃;-40℃~+350℃ |
Nominal pressure |
1.6MPa;2.5MPa;4.0MPa;6.3MPa |
Media type |
Liquid, gas, steam |
Accuracy class |
Liquid 1.0%; gas, steam 1.5% |
Measuring range ratio |
1:10 |
Medium temperature |
-40~350 degrees Celsius |
Power supply |
12~24V DC |
Output signal |
4~20mA |
